Foot Switch/ Pedal Switch
A footswitch is a rugged switch which is operated by foot pressure. An example of use is for the control of an electric sewing machine.
| Designation |
Model |
Rating |
Type of switch enclosed & contact arrangement |
Cable |
Cantact |
Action Force |
Material of Rind |
| Standard Type Momentary Action |
CFS-101 |
10A 250VAC |
Micro-switch momentary |
0.75mm2, 3C/0.5 Meter |
1A1B |
1.2 kg |
Plastics Aluminum Cast |
| CFS-102 |
15A 250VAC |
CM1704 |
0.75mm2, 3C/1Meter |
1A1B |
1.1 kg |
| CFS-3 |
10A 250VAC |
Micro-switch momentary 2PCS |
0.75mm2, 6C/1Meter |
2A2B |
1.2 kg |
| CFS-3S |
15A 250VAC |
CM1704 |
0.75mm2, 6C/1 Meter |
2A2B |
1.1 kg |
| Standard Type Alternate Action |
CFS-105 |
6A 250VAC |
Imported alternative switch |
0.75mm2, 2C/1 mete |
PUSH ON PUSH OFF |
2 kg |
Plastics Aluminum Cast |
| CFS-106 |
6A 250VAC |
Imported micro-switch |
0.75mm2, 3C/1 Meter |
PUSH 1A PUSH 1B |
1.5 kg |
Plastics |
| Mini Foot Switch Foot End Push |
CFS-201 |
10A 250VAC |
Micro-switch Momentary |
0.5mm2, 3C/1 Meter |
1A1B |
0.7 kg |
Plastics |
| CFS-01 |
10A 250VAC |
0.5mm2, 3C/1 Meter |
1A1B |
0.7 kg |
| CFS-1 |
10A 250VAC |
0.5mm2, 3C/1 mete |
1A1B |
0.9 kg |
| Protective Guard Foot Switch |
CFS-302 |
15A 250VAC |
CM1704 |
Accessory: Cable gland (No
cable) |
1A1B |
3.2 kg |
Plastics and Aluminum Cast |
| CFS-305 |
6A 250VAC |
Pushbutton switch alternate
action |
PUSH ON PUSH OFF |
3.1 kg |
| CFS-306 |
6A 250VAC |
Imported micro-switch |
PUSH 1A PUSH 1B |
3.5 kg |
| Large Type |
CFS-402 |
15A 250VAC |
CM1704 |
1A1B |
3.2 kg |
Notics:
1, Add R for waterproof available in CFS3 & CFS4.
2, Add Z for aluminum housing, available in CFS1, CFS3 & CFS4
