FK33

Model Reference

    Model Reference

Application

    Optional high-power axial fan "blowing" or "pumped" means the installation, ventilation function of the cascade of rain to prevent mechanical damage, but also to prevent the entry of rain, combined with sealed box protection class according to EN60529 / 10.91 up to IP54.

Technical Data

FK3321FK3321
FKL3321FKL3321
Fand Filter Type FK/ FKL 3321.100 3321.115 3321.024
Working Voltage V/ Hz 230V 50/60Hz 115V 50/60Hz 24(DC)
Air flow, free blowing 20/25m3/h
Flux of air equip filter exproted include filtering pad of standard 1xFK 3321.200; 15/18m3/h
Axial Fan Self-start screened magnetic pole motor Direct current motor
Rated Current 0.08A 0.16A 0.18A
Power 16W/14W 4.3W
Noise level 41/46dB(A)
Scope of temperature -10°C ~ 55°C
Exit Filter Type FK 3321.200

Dimensioned

Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
FK3321.100
Dimensioned
Dimensioned
Dimensioned
Dimensioned
Dimensioned
FK3321.200
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Head
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Installation
FK3322FK3322
FKL3322FKL3322
Fand Filter Type FK/ FKL 3322.100 3322.115 3322.024
Working Voltage V/ Hz 230V 50/60Hz 115V 50/60Hz 24(DC)
Air flow, free blowing 55/66m3/h
Flux of air equip filter exproted include filtering pad of standard 1xFK 3322.200; 43/50m3/h
2xFK 3322.200; 48/55m3/h
1xFK 3322.200; 48/55m3/h
Axial Fan Self-start screened magnetic pole motor Direct current motor
Rated Current 0.12/0.11A 0.24/0.23A 0.15A
Power 19W/18W 3.5W
Noise level 46/49dB(A)
Scope of temperature -10°C ~ 55°C
Exit Filter Type FK 3322.200

Dimensioned

Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
FK3322.100
Dimensioned
Dimensioned
Dimensioned
Dimensioned
Dimensioned
FK3322.200
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Head
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Installation
FK3323FK3323
FKL3323FKL3323
Fand Filter Type FK/ FKL 3323.100 3323.115 3323.024
Working Voltage V/ Hz 230V 50/60Hz 115V 50/60Hz 24(DC)
Air flow, free blowing 105/120m3/h
Flux of air equip filter exproted include filtering pad of standard 1xFK 3323.200; 71/82m3/h
2xFK 3323.200; 85/98m3/h
1xFK 3323.200; 78/90m3/h
Axial Fan Self-start screened magnetic pole motor Direct current motor
Rated Current 0.12/0.11A 0.24/0.23A 0.15A
Power 19W/18W 3.5W
Noise level 46/49dB(A)
Scope of temperature -10°C ~ 55°C
Exit Filter Type FK 3323.200

Dimensioned

Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
FK3323.100
Dimensioned
Dimensioned
Dimensioned
Dimensioned
Dimensioned
FK3323.200
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Head
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Installation
FK3325FK3325
FKL3325FKL3325
Fand Filter Type FK/ FKL 3325.100 3325.115 3325.024
Working Voltage V/ Hz 230V 50/60Hz 115V 50/60Hz 24(DC)
Air flow, free blowing 230/265m3/h
Flux of air equip filter exproted include filtering pad of standard 1xFK 3325.200; 170/205m3/h
2xFK 3325.200; 200/230m3/h
1xFK 3325.200; 190/215m3/h
Axial Fan Self-start screened magnetic pole motor Direct current motor
Rated Current 0.28/0.24A 0.53/0.49A 0.58A
Power 41W/38W 14W
Noise level 54/56dB(A)
Scope of temperature -10°C ~ 55°C
Exit Filter Type FK 3325.200

Dimensioned

Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
FK3325.100
Dimensioned
Dimensioned
Dimensioned
Dimensioned
Dimensioned
FK3325.200
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Head
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Installation
FK3326FK3326
FKL3326FKL3326
Fand Filter Type FK/ FKL 3326.100 3326.115
Working Voltage V/ Hz 230V 50/60Hz 115V 50/60Hz
Air flow, free blowing 500/560m3/h
Flux of air equip filter exproted include filtering pad of standard 1xFK 3326.200; 360/390m3/h
2xFK 3326.200; 440/495m3/h
Axial Fan Capacitance electromotion
Rated Current 0.29/0.35A 0.58/0.70A
Power 64W/80W
Noise level 46/49dB(A)
Scope of temperature -10°C ~ 55°C
Exit Filter Type FK 3326.200

Dimensioned

Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
Dimensioned Dimensioned
FK3326.100
Dimensioned
Dimensioned
Dimensioned
Dimensioned
Dimensioned
FK3326.200
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Head
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Dimensioned Dimensioned Dimensioned Dimensioned
Installation
